Valumark Polypropylene Barcode Labels

Features

  • Conforms to uneven or radius surfaces
  • An effective, affordable label for indoor asset tracking
  • Naturally receptive to thermal transfer printing
  • Roll format standard

An ideal solution for indoor asset tracking, “VALUMARK” Labels are an effective and affordable identification solution.

“VALUMARK” Labels are subsurface printed, which provides an extra layer of protection for logos, copy, and barcode against solvents, caustics, acids, and mild abrasion. This unique process eliminates the need for a laminate thereby eliminating the additional cost for the laminate as well as the possibility of delamination. The .002” thick adhesive provides excellent adhesion to hard-to-adhere-to plastic surfaces. The polypropylene material is naturally receptive to thermal transfer printing for possible on-site printing applications and easily conforms to uneven and curved surfaces.

Available with or without of barcode, “VALUMARK” Labels are produced using our digital printing process, which shows even the most detailed logos, type and artwork. Custom spot colors and four-color processing are also available at no additional charge.


Potential Applications for Valumark Polypropylene Barcode Labels

Asset Tracking – the barcode and human readable ID number on “VALUMARK” Labels can be used to track information about the asset the label is adhered to, i.e., laptops, furniture, containers, pallets, equipment and more.

OEM Product Identification – the barcode and/or product identification number on “VALUMARK” Labels can be used for tracking purposes such as warranty and service information and typically contain one or more of the following: model number, serial number, or part number. Customers use the identification plate on products they produce and sell.

Work-in-Process – the barcode and/or identification number on “VALUMARK” Labels can identify a “batch” OR “lot” of product or just simply identify each product as it travels through the production process.

Specifications Data
Material .002" thick white, silver or clear polypropylene
Bar Code & Serialization Serialized/unserialized numbers and bar code with human readable numbers
Label Copy The label copy may include block type, stylized type, logos or other designs
Colors Standard colors include black, red, yellow, green, dark blue, purple, orange or blue. Custom spot colors are also available at no additional charge. Due to contrast needed for the bar code scanner, all bar codes are black.
Standard Adhesive .002" thick pressure sensitive
Sizes 2" x 1"; 2" x .625"; 1.25" x .5"; 1.5" x .75"; 2" x .75"; 1.75" x .5"
Packaging Shipped on convenient rolls with scrap matrix removed for ease of removal. Cartons are clearly marked to indicate serial numbers of labels.
Shipment 11 business days
Destructive Test Data
Chemical Test Summary
This rating measures bar code readability and label adhesion after being exposed to chemicals listed below for a 2 hour soak
Chemical Test Data
Test conditions BC rating Label adhesion rating
Nitric acid no affect no affect
Hydrochloric acid no affect no affect
Caustic soda no affect no affect
Brake fluid no affect no affect
Acetone no affect no affect
Isopropyl alcohol no affect no affect
Speedball power cleaner no affect no affect
Glass cleaner no affect no affect
Water no affect no affect
Temperature Test Data
Read Range Test Data
Barcode Readability Test Data
Abrasion Test Summary
Label survived more than 500 revolutions on Taber Abrader using Calibrase H18 wheel with 1000g weight.
Abrasion Test Data
Label Adhesion Test Data
Pull Test Data
