Valumark Polypropylene Barcode Labels

Features

  • Conforms to uneven or radius surfaces
  • An effective, affordable label for indoor asset tracking
  • Naturally receptive to thermal transfer printing
  • Roll format standard

An ideal solution for indoor asset tracking, “VALUMARK” Labels are an effective and affordable identification solution.

“VALUMARK” Labels are subsurface printed, which provides an extra layer of protection for logos, copy, and barcode against solvents, caustics, acids, and mild abrasion. This unique process eliminates the need for a laminate thereby eliminating the additional cost for the laminate as well as the possibility of delamination. The .002” thick adhesive provides excellent adhesion to hard-to-adhere-to plastic surfaces. The polypropylene material is naturally receptive to thermal transfer printing for possible on-site printing applications and easily conforms to uneven and curved surfaces.

Available with or without a barcode, “VALUMARK” Labels are produced using our digital printing process, which shows even the most detailed logos, type and artwork. Custom spot colors and four-color processing are also available at no additional charge.

Specifications Data
Material .002" thick white, silver or clear polypropylene
Bar Code & SerializationSerialized/unserialized numbers and bar code with human readable numbers
Label CopyThe label copy may include block type, stylized type, logos or other designs
ColorsStandard colors include black, red, yellow, green, dark blue, purple, orange or blue. Custom spot colors are also available at no additional charge. Due to contrast needed for the bar code scanner, all bar codes are black.
Standard Adhesive.002" thick pressure sensitive
Sizes2" x 1"; 2" x .625"; 1.25" x .5"; 1.5" x .75"; 2" x .75"; 1.75" x .5"
PackagingShipped on convenient rolls with scrap matrix removed for ease of removal. Cartons are clearly marked to indicate serial numbers of labels.
Shipment8 business days
Destructive Test Data
Chemical Test Summary
This rating measures bar code readability and label adhesion after being exposed to chemicals listed below for a 2 hour soak
Chemical Test Data
Test conditionsBC ratingLabel adhesion rating
Nitric acidno effectno effect
Hydrochloric acidno effectno effect
Caustic sodano effectno effect
Brake fluidno effectno effect
Acetoneno effectno effect
Isopropyl alcoholno effectno effect
Speedball power cleanerno effectno effect
Glass cleanerno effectno effect
Waterno effectno effect
Temperature Test Data
Read Range Test Data
Barcode Readability Test Data
Abrasion Test Summary
Label survived more than 500 revolutions on Taber Abrader using Calibrase H18 wheel with 1000g weight.
Abrasion Test Data
Label Adhesion Test Data
Pull Test Data
